About This

• 【Replacement Part Number】Compatible With Grund-fos UPS15-58FC (UPS 15-58 FC); Replacement Number: 59896341.
• 【Widely Used】Our UPS15-58FC Circulator Pump is suitable for a wide range of applications, Suitable for commercial heating and air-conditioning systems and is also used for central and district heating systems.
• 【Parameters】 Max Pressure (PSI):145 psi. Horse Power:1/25HP. Max Flow (GPM):3.9 m³/h. Flow Range (GPM):0-17 GPM (Gallons Per Minute). Rated head: 3.19 m. Head Range (ft.):0-19.5. Max Head :5.9m. Hertz:60.
• 【Installation】Max ambient temperature: 40 °C; Amb. max at 80 dgr C liquid: 80 °C; Type of connection: 2-BOLT FLANGE (C.I. Flange); Pipe connection: 2-BOLT FLANGE; Pressure rating for connection: PN 10; Port-to-port length: 166 mm
• 【Excellent Performance】Our UPS15-58FC Circulator Pump Has Built-In Motor Protection, Which Prevents the Motor from Being Damaged in Abnormal Conditions Such as Overload or Short Circuit. When the Motor Runs Beyond the Rated Load, It Will Cut off the Power Supply in Time to Protect the Motor from Damage, So That Your Motor Will Last Longer and Perform Better. Our Motor Is Silent and Suitable for Installations That Are Sensitive to Sound.

Overview

• Brand : ZHENYUAN
• Color : Red
• Material : Cast Iron
• Style : Three-Speed Circulator Pump
• Power Source : AC
• Maximum Flow Rate : 17 Gallons Per Minute
• Voltage : 115 Volts
• Manufacturer : zhenyuan
